Technical characteristics
| Commercial Range | T9 - T9M |
|---|---|
| Torque | 400 Nm |
| Unwrapped height | 164 mm |
| Power supply | AC-RGE10-400V/50HZ THREE-PHASE |
| Speed | 8 rpm |
| Insulation class | Class I |
| Protection Index | IP 44 |
| Diameter | 90 mm |
| Type | Motors |
| Application | Industrial & commercial closure |
| Embedded Technologies | Wired |
| Consumption in standby mode | 0 W |
Compatibility & Applications
Embedded Technologies
-
Wired
Application
-
Industrial & commercial closure
Description
The most powerful torque range
- From 300 to 800nm with three-phase power supply. The t9 (800 nm) is the best compromise on the market offering both a compact solution and high lifting capacity (up to 800kg).
- Safety end-limit system a third switch cuts the power supply to the motor when going beyond the up or down limits, in accordance with en 12453.
Â
- From 300 to 800nm with three-phase power supply. The t9 (800 nm) is the best compromise on the market offering both a compact solution and high lifting capacity (up to 800kg).
- Safety end-limit system a third switch cuts the power supply to the motor when going beyond the up or down limits, in accordance with en 12453.
