Technical characteristics
| Commercial Range | T8 - T8M |
|---|---|
| Torque | 250 Nm |
| Unwrapped height | 125 mm |
| Unwrapped width | 130 mm |
| Power supply | AC - RGE 1 - 230V/50HZ |
| Speed | 8 rpm |
| Insulation class | Class I |
| Protection Index | IP 44 |
| Diameter | 80 mm |
| Type | Motors |
| Application | Industrial & commercial closure |
| Embedded Technologies | Wired |
| Consumption in standby mode | 0 W |
Compatibility & Applications
Embedded Technologies
-
Wired
Application
-
Industrial & commercial closure
Description
Wired single-phase
-The widest range of torque, from 150 to 450Nm with single phase power supply
-Safety end-limit system a third switch cuts the power supply of the motor when going beyond the up or down limits, in accordance with or without.
-The widest range of torque, from 150 to 450Nm with single phase power supply
-Safety end-limit system a third switch cuts the power supply of the motor when going beyond the up or down limits, in accordance with or without.
