Technical characteristics
| Commercial Range | T5 ZSP |
|---|---|
| Torque | 35 Nm |
| Power supply | AC - RGE 1 - 230V/50HZ |
| Speed | 17 rpm |
| Insulation class | Class I |
| Protection Index | IP 44 |
| Diameter | 50 mm |
| Type | Motors |
| Application | Exterior Vertical Screen |
| Embedded Technologies | Wired |
| Consumption in standby mode | 0.46 W |
Compatibility & Applications
-
Wired
-
Exterior Vertical Screen
Description
Torque 35 Nm - Speed 17 rpm
Power cable: 3 meters (black RNF)
Delivered by 10
Wired electronic, Ø 50 mm
- Detection of obstacle to descent with an automatic rise of the fabric in case of obstacle.
- 3 setting modes: automatic, semi-automatic and manual.
An universal screen motor for vertical screen
- Advanced features to match Zip screens specificities.
- Also compatible with standard screen but without obstacle detection.
- Available with and without pin.
- Simple behavior in case of obstacle with a one stop and liberation in case of obstacle detection.
