Technical characteristics
| Commercial Range | T5 AUTO Hz |
|---|---|
| Torque | 8 Nm |
| Radio Frequency | 433.420 MHz |
| Power supply | AC - RGE 1 - 230V/50HZ |
| Speed | 17 rpm |
| Insulation class | Class I |
| Protection Index | IP 44 |
| Diameter | 50 mm |
| Minimum internal diameter | 47 mm |
| Type | Motors |
| Application | Rolling shutter |
| Embedded Technologies | Hz |
| Consumption in standby mode | 0.38 W |
Compatibility & Applications
Embedded Technologies
-
Hz
Application
-
Rolling shutter
Description
ELECTRONIC END-LIMITS SYSTEM
…1 setting mode: FULL AUTOMATIC MODE.
STOP ON OBSTACLE FUNCTION
…the motor stops during the closing in case of an obstacle.
FROST DETECTION FUNCTION
…the motor stops during the opening if the shutter curtain is stuck in the guide rails
by frost or if the bottom lath is locked.
INTERMEDIATE POSITION FUNCTION
…it is possible to record a user’s favorite position.
SIMPLE PROGRAMMING
…SIMU-Hz/SIMU-BHz continuity: your installation and programming habits remain
the same as those of SIMU-Hz technology.
DESTRESSING FUNCTION AT THE UP AND DOWN END LIMIT
…in order to protect the roller shutter box and curtain.
