Technical characteristics
| Commercial Range | T5 AUTO |
|---|---|
| Torque | 20 Nm |
| Unwrapped height | 62 mm |
| Unwrapped width | 62 mm |
| Power supply | AC - RGE 1 - 230V/50HZ |
| Speed | 17 rpm |
| Approval | CE, NF, VDE |
| Insulation class | Class I |
| Protection Index | IP 44 |
| Diameter | 50 mm |
| Unwrapped length | 691 mm |
| Minimum internal diameter | 47 mm |
| Type | Motors |
| Application | Rolling shutter |
| Embedded Technologies | Wired |
| Consumption in standby mode | 0.47 W |
Compatibility & Applications
-
Wired
-
Rolling shutter
Description
NEW STAR SHAPED MOTOR HEAD …this new head can be swivelled through 360 degrees and it is fully compatible with all star shaped motor bracket on the market.
AUTOMATIC SETTING OF THE UP AND DOWN END-LIMITS …the roller shutter must be equipped with up and down stoppers.
STOP ON OBSTACLE FUNCTION …the motor stops when closing in the case of an obstruction.
FROST DETECTION FUNCTION …the motor stops when opening if the shutter curtain is stuck in the guide rails by frost or if the bottom lath is locked.
PERMANENT READJUSTMENT OF END-LIMITS …because of the constant auto-learning and revision of the up and down end-limit positions. It adapts thus to the variations in length of the shutter curtain over time
