Technical characteristics
| Commercial Range | T3.5 E |
|---|---|
| Torque | 4 Nm |
| Power supply | AC - RGE 1 - 230V/50HZ |
| Speed | 16 rpm |
| Insulation class | Class II |
| Protection Index | IP 44 |
| Diameter | 40 mm |
| Minimum internal diameter | 37 mm |
| Type | Motors |
| Application | Rolling shutter |
| Embedded Technologies | Wired |
| Consumption in standby mode | 0.32 W |
Compatibility & Applications
-
Wired
-
Rolling shutter
Description
ELECTRONIC END-LIMIT SYSTEM:
4 possible setting modes of the end-limits.
STOP ON OBSTACLE FUNCTION:
The motor stops during the closing in the case of an obstacle.
FROST DETECTION FUNCTION:
The motor stops during the opening if the shutter curtain is stuck in the guide rails by frost or if the bottom lath is locked.
